1734-IB8 — Allen-Bradley — Digital DC Sinking Input Module

Add to Wishlist
Add to Wishlist
SKU: 1734-IB8 Category: Tag:

Description

  • Estimated Lead Time : 7  working days.
  • Manufacturer : Allen-Bradley
  • Product No. : 1734-IB8
  • Product type : Digital DC Sinking Input Module
  • Inputs per module : 8 (1 group of 8), sinking
  • Terminal base screw torque : 0.8 Nm (7 lb-in.)
  • Module location : 1734-TB or 1734-TBS wiring base assembly
  • Indicators, network/module status : 1 green/red, logic side
  • Indicators, input status : 8 yellow, logic side
  • POINTBus current, max : 75 mA @ 5V DC
  • Module location : Between I/O modules in 1734 system. Breaks field power bus.
  • Power dissipation @ 28.8V DC, max : 1.6 W
  • Thermal dissipation @ 28.8V DC, max : 5.5 BTU/hr
  • Isolation voltage : 50V (continuous), Reinforced insulation type. Tested @ 2500V DC for 60 s, field-side to system
  • Relative humidity : IEC 60068-2-30 (Test Db, unpackaged nonoperating damp heat): 5…95% noncondensing
  • Vibration : IEC 60068-2-6 (Test Fc, Operating): 5 g @ 10…500 Hz
  • Dimensions HxWxD : 5.6cm x 1.2 cm x 7.55 cm
  • Shipping Weight : 3Kg
