Estimated Lead Time : 3 – 5 working days.
Manufacturer : Allen-Bradley
Product No. : 1734-IE4C
Product type : POINT I/O 4 Channel High Density Current Input Module
Number of inputs : Number of inputs 4, single-ended, non-isolated, current
Resolution : 16 bits ??over 0??1 mA 0.32 碌A/cnt
Absolute accuracy Current terminal : 0.1% Full Scale @ 25 掳C
Absolute accuracy : 0.1% Full Scale @ 25 掳C (77 掳F)
Accuracy drift w/temp. Current terminal : 30 ppm/掳C
Input impedance/resistance : 60 O
Conversion type : Delta Sigma
Terminal base : 1734-TB3, 1734-TB3S wiring base assembly
POINTBus current, max : 75 mA
Power dissipation, max : 0.55 W @ 28.8V DC
Thermal dissipation, max : 2.0 BTU/hr @ 28.8V DC
Supply voltage, backplane : 5V DC
Input current : 4??0 mA or 0??0 mA
Isolation voltage : 50V, tested @ 1500V AC for 60 s, inputs and field power to system. No isolation between individual inputs or inputs to field power.
Keyswitch position : 3
Enclosure type rating : None (open-style)
Dimensions (HxWxD), approx. : 5.6cm x 1.2cm x 7.55cm
Shipping Weight : 2 Kg
