Estimated Lead Time : 7-10 working days.
Manufacturer : Allen-Bradley
Product No. : 1734-OB4E
Product type : POINT I/O Protected Output Module
Number of outputs, non-isolated, sourcing : 4 (1 group of 4)
On-state voltage, min : 10V DC
On-state voltage, nom : 24V DC
On-state voltage, max : 28.8V DC
On-state voltage drop, max : 0.2V DC
Output current rating : 1.0 A per output, not to exceed 3.0 A max per module
Surge current : 2 A for 10 ms, repeatable every 3 s
Keyswitch position : 1
Terminal base screw torque : 0.8 Nm (7 lb-in.)
Module location : 1734-TB or 1734-TBS wiring base assembly
POINTBus current, max : 75 mA @ 5V DC
Power dissipation @ 28.8V DC, max : 1.2 W
Thermal dissipation @ 28.8V DC, max : 4.1 BTU/hr
Isolation voltage : 50V (continuous), Reinforced Insulation Type. Tested @ 2500V DC for 60 s, field-side to system.
External DC power supply voltage, nom : 24V DC
External DC power voltage range : 10…28.8V DC
Dimensions (HxWxD), approx. : 5.6cm x 1.2cm x 7.55cm
Shipping Weight : 2 Kg
