1734-OB8S
1734-OB8S — Allen-Bradley — POINT Guard I/O Safety Modules
due to the dynamic changes in the price and stock quantity, the price need negotiation
$260.00
- Estimated Lead Time : 3 working days.
- Manufacturer : Allen-Bradley
- Product No. : 1734-OB8S
- Product type : POINT Guard I/O Safety Modules
- Outputs per module : 8
- Output type : Current sourcing
- Output current (each output point), max : 1 A
- Residual voltage (drop) : <0.6V
- Leakage current, max : 0.1 mA
- Short-circuit protection : Electronic
- Reaction time : <6.2 ms
- POINTBus current, max : 190 mA
- Power dissipation, max : 3.02 W
- Thermal dissipation : 10.32 BTU/hr
- Isolation voltage : 50V (continuous), Basic Insulation Type between field side and system. No isolation between individual channels Type tested @ 707V DC for 60 s.
- Power bus, operating supply voltage, nom : 24V DC
- Dimensions (HxWxD), approx. : 7.7cm x 2.4 cm x 5.5 cm
- Shipping Weight : 2Kg
