Estimated Lead Time : 7 – 10 working days.
Manufacturer : Allen-Bradley
Product No. : 1794-OB16
Product type : FLEX Digital DC Output Module
Voltage, on-state output, nom : 24V DC, sourcing
Voltage, on-state output, min : 10V DC
Voltage, on-state input, max : 31.2V DC
Voltage drop, on-state output, max : 0.5V DC
Terminal base unit : 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TB3K, 1794-TB3SK
Current, on-state output, min : 1.0 mA per channel
Current, off-state output, max : 500 mA per channel, 8 A per module
Leakage current, off-state output, max : 0.5 mA
Output surge current, max : 2 A for 50 ms, repeatable every 2 s
External DC supply current range : 20??5 mA
Power dissipation, max : 5.3 W @ 31.2V DC
Thermal dissipation, max : 18.1 BTU/hr @31.2V DC
Isolation voltage : 50V continuous, I/O to system Tested to 850V DC for 1 s, I/O to system No isolation between individual channels
Dimensions HxWxD cm : 4.6 x 9.4 x 5.3 cm
Shipping Weight : 4 Kg
