6AV6643-0CD01-1AX1 — Siemens — SIMATIC MP277 10″ Touch Multi Panel
the i tem now replaced by a MP 277/MP 377 panel family, but they have been discontinued themselves since 2015.
Now you only option is to use a new-generation Comfort panel; these can only be programmed with WinCC v13 Comfort (or higher version).
if you need it just for maintenance,we can provide you equivalent.or use use this new version COMFORT PANEL type : 6AV2124-0MC01-0AX0, but a little minor adjustments code.
$520.00
- Estimated Lead Time : 3 – 5 working days.
- Manufacturer : Siemens
- Product No. : 6AV6643-0CD01-1AX1 6av6 643-0cd01-1ax1
- Product type : SIMATIC MP277 10″ Touch Multi Panel
- Customer-specific configuration : Yes
- Design of display : TFT
- Screen diagonal : 10.4 in
- Color type : Colors
- Horizontal image resolution : 640 Pixel
- Vertical image resolution : 480 Pixel
- Resolution (WxH in pixel) : 640 x 480
- MTBF backlighting (at 25 掳C) : 50 000 h
- Control elements : Touch screen
- Keys with LED : No
- System keys : No
- Numeric/alphabetical input Yes / Yes
- Mounting position : vertical
- Type of supply voltage : DC
- Processor type : ARM
- Type of memory : Flash / RAM
- Capacity of main memory, max. : 128 Mbyte
- Clock Type : Hardware clock, battery backup, synchronizable
- Interfaces/bus type : 1 x RS422, 1 x RS485, 1 x Ethernet (RJ45)
- Shipping Weight : 8 Kg
