Brand

FESTO

Flow Direction

Other
3C Valve Category

Industry

Application Areas
Chemical, Mining, Road/Rail/Marine, Comprehensive

FESTO Solenoid Valve

Technical Specifications

Valve Function
Two-position 5-way dual electric control

Actuation Method
Electric control

Width
14 mm

Standard Nominal Flow Rate
800 l/min

Working Port
G1/8

Working Voltage
24V DC

Working Pressure
0.2 MPa … 0.8 MPa

Working Pressure
2 bar … 8 bar

Structural Features
Piston Gate Valve
Marine Classification
See Certificates

Protection Rating
IP65 IP67 with plug-in socket conforming to IEC 60529 standard

Nominal Diameter
6 mm

Break Function
With throttling option

Sealing Principle
Soft seal
Installation Position
Optional
Manual Control
Push-button type with accessory lock

Pilot Type
Pilot Actuation
Pilot Air Source
Internal Pilot

Flow Direction

Irreversible

Symbol

00991013

Valve Position Code

Label Clip

Overlap

Positive Overlap

Reverse Switching Time

12 ms

Continuous On-Time

100%

Maximum Positive Test Pulse for Signal 0

1200 µs

Maximum Negative Test Pulse for Signal 1

900 µs

Coil Characteristics

24 V DC: 1.28 W

Permissible Voltage Fluctuation

-15%/+10%

Operating Medium

Compressed air, conforming to ISO 8573-1:2010 [7:4:4]

Operating and Pilot Medium Description

Can be operated with lubricating medium (must be operated with lubricating medium continuously thereafter)

Vibration Resistance

Transportation application test, severity level 2, conforming to FN 942017-4 and EN 60068-2-6

Shock Resistance

Shock test, severity level 2. Complies with FN 942017-5 and EN 60068-2-27

Corrosion Resistance Rating CRC

2 – Medium corrosion resistance

Medium Temperature

-5 °C … 50 °C

Ambient Temperature

-5 °C … 50 °C

Maximum Tightening Torque of Connectors

0.4 Nm

Product Weight

115 g

Electrical Interface

4-pin M8x1

Mounting Method

With Through Hole

Pilot Exhaust Port 82

M3
Pilot Exhaust Port 84

M3
Pilot Air Port 12

M3
Pilot Air Port 14

M3
Air Connector, Air Port 1

G1/8
Air Connector, Air Port 2

G1/8
Air Connector, Air Port 3

G1/8
Air Connector, Air Port 4

G1/8
Air Connector, Air Port 5

G1/8

Material Specifications

RoHS Compliance

Sealing Material

NBR

Housing Material

Die-cast Aluminum

FESTO Solenoid Valve Environmental Conditions

1) The maximum and minimum ambient temperatures should be within the allowable range;

2) In environments with high relative humidity or exposure to water droplets and rain, waterproof solenoid valves should be selected;

3) In environments with frequent vibration, bumps, and impacts, special types should be selected, such as marine solenoid valves;

4) In corrosive or explosive environments, corrosion-resistant types should be selected based on safety requirements;

5) If space is limited, multi-functional solenoid valves should be selected, as they eliminate the need for bypasses and three manual valves and facilitate online maintenance.

FESTO solenoid valves are electromagnetically controlled industrial devices, fundamental components of automation used to control fluids. They are actuators, not limited to hydraulic or pneumatic systems. They are used in industrial control systems to adjust the direction, flow rate, speed, and other parameters of the medium. Solenoid valves can be used with different circuits to achieve the desired control, while ensuring control accuracy and flexibility. There are many types of solenoid valves, each playing a different role in a control system. Commonly used types include check valves, safety valves, directional control valves, and speed control valves.
