Brand

FESTO
Flow Direction
One-way
3C Valve Category
Industrial
Application Areas
Environmental Protection, Biotechnology, Petroleum, Pharmaceutical/Biopharmaceutical, General
FESTO Solenoid Valve 577267 in Stock

FESTO solenoid valves are fundamental automation components used to control fluids. They are actuators, not limited to hydraulic or pneumatic systems. They are used in industrial control systems to adjust the direction, flow rate, speed, and other parameters of the medium. Solenoid valves can be used with different circuits to achieve the desired control, ensuring both precision and flexibility. There are many types of solenoid valves, each playing a different role in the control system. Commonly used types include check valves, safety valves, directional control valves, and speed control valves.

FESTO Solenoid Valve Working Principle

The FESTO solenoid valve contains a sealed chamber with through-holes at different positions, each connecting to a different oil pipe. Inside the chamber is a piston, flanked by two electromagnets. When the coil of one electromagnet is energized, the valve body is attracted to that side. Controlling the movement of the valve body opens or closes different drain holes. The inlet hole is always open, allowing hydraulic oil to enter different drain pipes. The oil pressure then pushes the piston in the cylinder, which in turn moves the piston rod, which in turn drives the mechanical device. Thus, controlling the flow of current to the electromagnets controls the mechanical movement.

Festo – Standard Namur Valve (VDE/VDI 3845) Product List My Favorites Features a NAMUR type connection face with a connection hole, conforming to VDE/VDI 3845 standard. Does not include a solenoid coil or socket.

Order Number Order Code 1 Valve Function Standard Rated Flow Pneumatic Connection Port 1 Drive Type

VSNC-FC-M52-MD-G14-FN; 577267 can replace 183973 MFH-5/2K-FR-NA 5/2

183973 MFH-5/2K-FR-NA 5/2 Single Solenoid 1000 l/min Base Electric

183974 MN1H-5/2K-FR-NA 5/2 Single Solenoid 1000 l/min Base Electric

183977 MFXMH-5/2K-FR-NA 5/2 Single Electric Control 1000 l/min Base Electrical

183978 MGTBH-5/2K-FR-NA 5/2 Single Electric Control 400 l/min Base Electrical

188400 MGTBH-5/2K-FR-110AC-NA 5/2 Single Electric Control 400 l/min Base Electrical

188401 MGTBH-5/2K-FR-230AC-NA 5/2 Single Electric Control 400 l/min Base Electrical

535987 NVF3-MOH-5/2-K-1/4-EX Two-position 5-way or two-position 3-way Single Electric Control 900 l/min G1/4 Electrical

535988 NVF3-MOH-5/2-K-1/4-IA-EX Two-position 5-way or two-position 3-way Single-electric control, 900 l/min, G1/4 electrical type

541645 NVF3-5/2K-1/4-24-EX 5/2 Normally open, single-electric control, 900 l/min, G1/4 electrical type

541646 NVF3-5/2K-1/4-24-NPT-EX 5/2 Normally open, single-electric control, 900 l/min, NPT1/4-18 electrical type

541647 NVF3-5/2K-1/4-120-EX 5/2 Normally open, single-electric control, 900 l/min, G1/4 electrical type

541648 NVF3-5/2K-1/4-120-NPT-EX 5/2 Normally open, single-electric control, 900 l/min, NPT1/4-18 electrical type

547017 VSNB-FC-M52-M-G14-P2 5/2 and 3/2 Single Electric Control 950 l/min G1/4

547019 VSNB-FC-M52-M-G14-1A1-EX4A 5/2 and 3/2 Single Electric Control 950 l/min G1/4 Electrical

547021 VSNB-F-M52-M-G14-P2 5/2 Single Electric Control 950 l/min G1/4

547022 VSNB-F-B52-G14-P2 5/2 Bistable 950 l/min G1/4

547023 VSNB-F-M52-M-G14-1A1-EX4A 5/2 Single Electric Control 950 l/min G1/4 Electrical

547024 VSNB-F-B52-G14-1A1-EX4A 5/2 Dual-Stable 950 l/min G1/4 Electrical

547026 VSNB-FC-M52-MH-G14-1A1 5/2 and 3/2 Single Electrical Control 950 l/min G1/4 Electrical

547028 VSNB-F-M52-MH-G14-1A1 5/2 Single Electrical Control 950 l/min G1/4 Electrical

FESTO Solenoid Valve Selection Criteria:

1. Select the solenoid valve based on pipeline parameters: nominal diameter (DN) and connection method.

1) Determine the nominal diameter (DN) according to the inner diameter of the pipeline or flow requirements on site;

2) Connection method: Generally, for DN>50, a flange connection should be selected; for DN≤50, the connection method can be freely selected according to user needs.

2. Selection of Solenoid Valves Based on Fluid Parameters: Material and Temperature Group

1) Corrosive fluids: Corrosion-resistant solenoid valves and all-stainless steel valves are recommended; Ultra-clean edible fluids: Food-grade stainless steel solenoid valves are recommended;

2) High-temperature fluids: Solenoid valves made with high-temperature resistant electrical and sealing materials should be selected, and piston-type valves are preferred;

Solenoid Valve

Solenoid Valve

3) Fluid state: Fluids can be gaseous, liquid, or mixed, especially for diameters greater than DN25, which must be clearly distinguished;

4) Fluid viscosity: Generally, any viscosity can be selected below 50 cSt. If this value is exceeded, a high-viscosity solenoid valve should be selected.

3. Selecting Solenoid Valves Based on Pressure Parameters: Principle and Structure

1) Nominal Pressure: This parameter has the same meaning as other general-purpose valves, determined by the nominal pressure of the pipeline.

2) Working Pressure: If the working pressure is low, a direct-acting or step-direct-acting principle must be selected. For a minimum working pressure difference of 0.04 MPa, direct-acting, step-direct-acting, and pilot-operated valves can all be selected.

4. Electrical Selection: AC220V and DC24V voltage specifications should be prioritized for convenience.

5. Selecting Based on Continuous Working Time: Normally Closed, Normally Open, or Continuously Energized

1) When the solenoid valve needs to be open for a long time, and the continuous time is longer than the closing time, a normally open type should be selected.

2) If the opening time is short or the opening and closing times are infrequent, a normally closed type should be selected.

3) However, for some safety protection applications, such as furnace and kiln flame monitoring, normally open valves cannot be selected; a continuously energized type should be chosen. 6. Select auxiliary functions according to environmental requirements: explosion-proof, backflow prevention, manual operation, waterproof mist, water spray, and diving.

Technical Specifications

Valve Function
Two-position 5-way or two-position 3-way, convertible

Actuation Method
Electrically controlled

Width
32 mm
Standard Nominal Flow Rate
1250 l/min

Working Port
NAMUR Orifice Type

Working Voltage
Through solenoid coil, must be ordered separately

Working Pressure
0.25 MPa … 0.8 MPa

Working Pressure
2.5 bar … 8 bar

Structural Features
Piston gate valve

Reset Type
Spring return

Certificate Issuing Mechanism
DNVGL-TAA000011J

Exhaust Function
With throttling option

Sealing Principle
Soft seal
Installation Position
Optional
Compliant Standards
VDI/VDE 3845 (NAMUR)

Manual Control
Lock-lock push-button type

Pilot Type
Pilot-driven

Pilot Air Source
Internal pilot

Flow Direction
Irreversible

Symbol
00991831
Overlap
Positive Overlap

Signal Status Indicator

Installation via Accessory

b Value

0.4

c Value

5.2 l/sbar

Standard Nominal Flow Rate, Exhaust Return 4->3

110 l/min

Close Time

92 ms

Open Time

35 ms

Continuous On-Time

100%

Coil Characteristics

Please refer to the electromagnetic coil; must be ordered separately

Explosion-proof

Information in the certificate must be followed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)

Working Medium

Compressed air, conforming to ISO 8573-1:2010 [7:4:4]

Working and Pilot Medium Description

Can be operated with lubricating media (must be operated with lubricating media continuously thereafter)

Corrosion Resistance Rating CRC

2 – Medium corrosion resistance

Paint Wetting Defect Substance (PWIS) Compliance

VDMA24364-B2-L

Media Temperature

-20 °C … 60 °C

Ambient Temperature

-20 °C … 60 °C

Product Weight

415 g

Installation Method

With through-hole

Ventilation Interface

Non-pipe type

Air inlet, port 1

G1/4

Air inlet, port 2

NAMUR port mode

Air inlet, port 3

G1/4

Air inlet, port 4

NAMUR port mode
Air inlet, air port 5

G1/4

Material Specifications

RoHS Compliant

Sealing Material

NBR

Housing Material

Refined Aluminum Alloy

Screw Material

High Alloy Stainless Steel
