Brand

FESTO
Flow Direction
Other
3C Valve Category
Industry
Application Areas
Medical & Health, Chemical, Bio-industry, Petroleum, Packaging/Paper/Printing
FESTO Solenoid Valve
FESTO single-acting solenoid valve, also known as a single-electrode solenoid valve, comes with accessories such as quick-connect fittings, barbed pipe fittings, other pipe fittings, silencers, connecting accessories, electrical accessories, etc.

Working Principle of German FESTO Solenoid Valves

:
German FESTO solenoid valves

contain a sealed chamber with through-holes at different positions, each leading to a different oil pipe. The valve is located in the center of the chamber, flanked by two electromagnets. When the coil of one electromagnet is energized, the valve body is attracted to the side. By controlling the movement of the valve body, different drain holes are blocked or opened. The inlet hole is always open, allowing hydraulic oil to enter different drain pipes. The oil pressure then pushes the piston of the hydraulic cylinder, which in turn drives the piston rod, which in turn drives the mechanical device. Thus, controlling the current to the electromagnet controls the mechanical movement.

The iron core inside the magnetic sleeve of the FESTO solenoid valve eliminates the need for a dynamic seal, making external leakage easily preventable. Electric valves are difficult to control torque, prone to internal leakage, and can even break the valve stem head; the structure of the solenoid valve easily controls internal leakage, reducing it to zero. Therefore, solenoid valves are particularly safe to use, especially for corrosive, toxic, or high/low temperature media. Festo cylinders, solenoid valves, pneumatic valves, manual valves, and mechanical valves; Festo products are widely used in many industries, such as automotive, electronics, food processing and packaging, gripping and assembly and industrial robots, water treatment, chemicals, rubber, plastics, textiles, machine tools, metallurgy, construction machinery, rail transportation, papermaking, and printing. To address the specific needs of various industries, Festo has five industry management departments: Automotive, Food & Packaging, Electronics, Gripping Systems, and Process Control, specifically designed to meet the unique requirements of these sectors.

FESTO Solenoid Valve Technical Specifications:

Actuation Type: Electric

Standard Rated Flow: 7500 l/min

Operating Pressure: 2 – 8 bar

Design Structure: Lift-up valve seat

Reset Type: Mechanical spring

Protection Class: IP65

Rated Size: 19 mm

MFH-3-1/4 Exhaust Function: Throttling

Sealing Principle: Soft

Mounting Position: Any

Manual Control: Position locked

Pilot Type: Pilot controlled

Flow Direction: Irreversible

Switching Time, Closed: 32 ms

Switching Time, Opened: 36 ms

Working Medium: Filtered compressed air, Filtration Class: 40, Lubricated or unlubricated

Medium Temperature: -10 – 60 °C

Ambient Temperature: -5 – 40 °C

Product Weight: 1260 g

Electrical Connection: Via F coil, must be ordered separately

Mounting Type: Optional

MFH-3-1/4 with through-hole

On air rail
Pilot exhaust port 82 M5

Pneumatic connection Port 1 G3/4

Pneumatic connection Port 2 G3/4

Pneumatic connection Port 3 G3/4

Seal material information: NBR

Housing material information: Die-cast aluminum
